Trade Size |
Material Diameter |
Nominal Inside Length |
Nominal Inside Width |
Work Load Limit (MAX.) |
Proof Test (MIN.) |
Breaking Force (MIN.) |
|||||||
|
mm |
in |
mm |
in |
mm |
in |
mm |
LBS |
KG |
LBS |
KN |
LBS |
KN |
4 |
3.0 |
0.120 |
3.0 |
0.55 |
14.0 |
0.21 |
5.3 |
215 |
98 |
430 |
1.91 |
860 |
3.82 |
3 |
3.4 |
0.135 |
3.4 |
0.59 |
15.0 |
0.24 |
6.1 |
270 |
122 |
540 |
2.40 |
1080 |
4.80 |
2 |
3.8 |
0.148 |
3.8 |
0.61 |
15.5 |
0.26 |
6.6 |
325 |
147 |
650 |
2.89 |
1300 |
5.78 |
1 |
4.1 |
0.162 |
4.1 |
0.63 |
16.0 |
0.28 |
7.1 |
390 |
177 |
780 |
3.47 |
1560 |
6.93 |
1/0 |
4.5 |
0.177 |
4.5 |
0.74 |
18.8 |
0.31 |
7.9 |
465 |
211 |
930 |
4.14 |
1860 |
8.27 |
2/0 |
4.9 |
0.192 |
4.9 |
0.78 |
19.8 |
0.34 |
8.6 |
545 |
247 |
1090 |
4.85 |
2180 |
9.69 |
3/0 |
5.3 |
0.207 |
5.3 |
0.85 |
21.6 |
0.36 |
9.1 |
635 |
288 |
1270 |
5.65 |
2540 |
11.29 |
4/0 |
5.5 |
0.218 |
5.5 |
0.99 |
25.1 |
0.38 |
9.6 |
700 |
318 |
1400 |
6.23 |
2800 |
12.44 |
5/0 |
6.4 |
0.250 |
6.4 |
1.07 |
27.2 |
0.44 |
11.2 |
925 |
420 |
1850 |
8.23 |
3700 |
16.44 |
